Pilot 3101000 Vertical Compressed Air Storage Tank

The Pilot 3101000 Vertical Compressed Air Storage Tank is part of our range of vertical air receivers for compressed air storage. Custom built and horizontal air receivers are also available.

  • 1000L capacity
  • 1100 kpa
  • 2460mm height

    REQUEST A QUOTE

    Specifications

    Model Capacity Working Pressure A B C D E F G H
    (L) (KPA) (mm) (mm) (mm) (mm) Inches(BSP) Inches(BSP) Inches(BSP) Inches(BSP)
    3101000 1000 1100 2460 800 720 1170 1½” 2″ ½” 2″
    • WorkCover NSW Plant Design Registered
    • Technical data conforms to +/- 5%. Pilot Air reserves the right to modification without notice for design and technical improvements.
    • For over 40 years Pilot Air Compressors has been meeting the needs of industry. Ask us about your requirements.

    Finished in industrial grade enamel, the Pilot 3101000 Vertical Compressed Air Storage Tank is manufactured to AS1210-3 and provided with the manufacturer’s data report. Supplied as standard with safety valve, pressure gauge and manual condensate drain, you can rest easy with this compressed air storage solution.
